PCB Manufacturer Luxembourg
Over the past ten years, PCB Runner, a PCB manufacturer in Luxembourg, has seen significant success. Our company currently manufactures circuit boards with all necessary capabilities. We are currently the most renowned solution supplier in Luxembourg. We have clients all around the world and serve a wide range of sectors.
Get a Free Quote Now
PCB Manufacturing and Prototype Luxembourg
We at PCB Manufacturer Luxembourg are the most well-known and reliable choice for full-feature printed circuit board manufacture since we offer a variety of board kinds and are remarkably adaptable in how we approach problem-solving.
We are offering following categories:
∙ Multilayer layer PCBs
∙ Flex and Rigid-Flex PCBs
∙ Hybrid RF PCBs, RF Boards
∙ Ceramic, High Temperature Boards, Heavy Copper Boards
∙ High Speed Boards, High Frequency Boards
∙ Metal Core and Aluminum Backed Circuit Boards
Our special services include
Our full-feature circuit board manufacturing detailed capabilities are following
|
Parameters |
Specifications For Rigid |
Specifications For Flex |
|
Maximum Panel Size |
400 mm x 450mm |
|
|
Layers |
1-50 layer |
1-20 layer |
|
Copper Thickness |
Inner (minimum) Hoz – (Max) 6oz Outer (minimum) Hoz – (Max) 6oz
|
Inner (minimum) Hoz – (Maximum) 3oz Outer (minimum) Hoz – (Maximum) 3oz |
|
Board Material |
FR4: KB6164, KB6167, S1000-2M, S1000H, TG150: KB6165 Rogers: R4350B, R4003C MetalCore: T111 AL Halogen: S1150G TG135:ShengyiS1141/ KB6160 (CTI175-249） |
Polymide: Thinflex PI, Panasonic PI Rogers: NA Metal Core:NA Halogen:NA |
|
Inner line width/ Line spacing (original) |
1oz = minimum 3 mil& max no limited 2oz = minimum 6 mil 3oz = minimum 8.5 mil 4oz = minimum 11 mil 5oz = minimum 14 mil 6oz = minimum 18 mil |
1oz = minimum 2.5mil & max not limited. 2oz = minimum 6 mil 3oz = minimum 8 mil |
|
Outer line width/ Line spacing (original) |
1oz = minimum 3mil & max: not limited 2oz = minimum 6 mil 3oz = minimum 9 mil 4oz = minimum 12 mil 5oz = minimum 15 mil 6oz = minimum 19 mil |
1oz = minimum 3mil & max: not limited 2oz = minimum 6 mil 3oz = minimum 8 mil |
|
Line width tolerance |
minimum +/-10% & max +/-20% |
minimum +/-10% & max +/-20% |
|
The impedance value and tolerance |
minimum 40+/-5% ohm & max 120ohm +/-10% |
minimum 40+/-5% ohm & max 120ohm +/-10% |
|
The group of impedance |
min & max, no group QTY limited, we can calculate the impedance per your spec |
min& max, no group QTY limited, we can calculate the impedance per your specs |
|
solder mask bridge |
Glossy Colors, Minimum Bridge: 3.5mil
MATTE Colors, Minimum Bridge: 4mil |
Glossy Colors, Minimum Bridge: 3.5mil
MATTE Colors, Minimum Bridge:4mil |
|
Vias |
Blind, Buried, Plugged, Via-in-Pad, Micro via |
|
|
Board Thickness |
(minimum & Max): 0.2-10mm |
(minimum & Max): 0.1-0.40mm |
|
Thickness Tolerance |
(minimum & Max): +/-0.10mm & +/-10% |
(minimum & Max): +/-0.03mm & +/-0.10mm |
|
Solder Mask |
Type of Color & Glossy/MATTE Glossy green/matte green Glossy red/matte red Glossy blue Gossy black/matte black Glossy yellow Glossy white Glossy Purple |
Type of Coverlay Color & soldermask color Amber coverlay Black coverlay Glossy green soldermask Glossy blue Gossy black |
|
Surface Finish |
Finish Type with Thickness ENIG: gold 1-3u” and Ni 80-160u” HASL-LF, Tin thickness is 1-40um. OSP: 8-20u” Hard gold fingers: gold 3-40u” and Ni 80-160u” Immersion silver: Ag 6-15u” ENEPIG: gold 1-2u” and Ni 80-120u”, Pa:1-2u” Immersion Tin |
Finish Type with Thickness ENIG: gold 1-3u” and Ni 80-160u” HASL-LF, Tin thickness is 1-40um. OSP: 8-20u” Hard gold fingers: gold 3-40u” and Ni 80-160u” Immersion silver: Ag 6-15u” ENEPIG: gold 1-2u” and Ni 80-120u”, Pa:1-2u” |
|
Minimum dimensions |
Dimensions with routing method Min. board size is 20*30mm. Min. routing width is 0.8mm |
Dimensions with routing method Min. board size is 10*10mm |
|
Resin Plug Hole(finished) |
Dimensions with routing method Min holes size is 0.10mm, max is 0.50mm |
Dimensions with routing method Min holes size is 0.10mm, max is 0.50mm |
|
Castellated Holes |
Clearance with routing method min hole is 0.50mm |
Clearance with routing method min hole is 0.50mm |
|
Legend Printing |
White or Custom Colors |
White or Custom Colors |
|
The height/width of silkscreen |
（word height 0.8mm/ word width 0.40mm ratio）2:1 |
（word height 0.8mm/ word width 0.40mm ratio）2:1 |
|
The impedance value and tolerance |
minimum 40+/-5% ohm & max 120ohm +/-10% |
|
|
The group of impedance |
minimum & max, no group QTY limited, we can calculate the impedance per your spec |
|
|
The height/width of silkscreen |
（word height 0.8mm/ word width 0.40mm ratio）2:1 |
|
|
External dimension tolerance
|
± 5 mil |
± 5 mil |
|
The board thickness of V-CUT |
we can only do v-cut for board thickness from 0.60-2.0mm |
± mil, o v-cut for flex boards, it’s too thin. |
|
V-CUT Angle specifications |
20/30/45/60-degree Angles |
Angles, no v-cut for flex boards, it’s too thin. |
|
V-CUT Angle tolerance |
± 5degree |
± mil—no v-cut for flex boards, it’s too thin. |
|
BOARD ROUTING METHOD |
CNC |
laser cut and punching |
|
Edge plating with thickness |
20um copper on edge plating |
15um |
|
Mini distance between test point and plate edge |
0.2mm |
0.2mm |
|
Fixture test Max size |
Dimensions (500mm × 600 mm) |
Dimensions (450mm × 558mm) |
|
Thickness of peelable solder mask |
minimum 0.075 – max 0.20(mm) |
minimum 0.075- max 0.20(mm) |
|
IPC standard |
IPC-6012 |
IPC-6012 |
|
Kapton tape |
Thickness：0.03,0.05, 0.07 mm |
Thickness：0.05mm |
|
BGA PITCH |
minimum 0.10mm- max 0.12(mm) |
minimum 0.10mm- max 0.12(mm) |
|
Blind VIA / BURRIED VIA |
minimum – max (mm) Stacked 0.10mm Staggered 0.10mm |
minimum – max (mm) Stacked 0.10mm Staggered 0.10mm |
|
Laser Drill Size |
Minimum (mm) 0.10 Max (mm) 0.12 |
Minimum (mm) 0.1 Max (mm)0.1 |
|
Aspect Ratio |
Laser Drill (minimum 1:1.3& standard 1:1) Mechanical Drill (minimum 1:12& standard 1:8) |
Laser Drill (minimum 1:1 & standard 1:1) Mechanical Drill (minimum 1:2& standard 1:1) |
|
Back drilling |
Yes, we can do it. |
N/A |
|
Lead Times |
2 days |
|
PCB manufacturer Luxembourg also offers edge plating, Carbon mask, and Kapton tape. Peelable solder masks, gold fingers, etc. For impedance control PCBs, we may change the base material, layer stackup, and other components to obtain tolerance limitations of 10%.
Full-Feature Circuit Board Manufacturing Capabilities Luxembourg
o Quick Turn
o Prototype
o Mass Production
Cost-Free Special Services
∙ DFM and DFA Checks
∙ Penalization
∙ Electrical Testing
∙ Stencil Making
∙ Custom Layer Stack-up
∙ Consultation to reduce Board Production Costs
∙ Expedited Circuit Fabrication
Flex and Rigid-Flex PCB Manufacture Luxembourg
PCB Runner peruses incredibly in rigid and rigid-flex to provide our valuable customers with one-stop quick-turn fabrication and assembly services worldwide. To enable customers to speed up their R&D, we respond to RFQs immediately, carry out DFM checks on the same day, and offer rapid production.
Types of Flex and Rigid-Flex Boards We Are Offering:
∙ Single-sided Flex/ Double-sided Flex
∙ Single-sided Rigid-Flex/ Double-sided Rigid-Flex
∙ Multi-layered Flex
∙ Multi-layered Rigid-Flex
Customers can speak with our design and engineering services team to select the optimal design for their needs if they have requirements. With the assistance of our quick turn, rapid prototyping service, our customers can rapidly evaluate their new designs.
HDI PCB Luxembourg
To ensure the customer’s project success, PCB Manufacturer Luxembourg has a capable engineering staff with highly skilled and dedicated professionals in cutting-edge technology. Our staff makes certain that dependable customers begin with an optimized design that has a greater chance of meeting deadlines.
PCB Runner— PCB Assembly Luxembourg
We offer a whole package of services for PCB assembly. We offer a range of services under one roof, including component sourcing, board assembly, and testing. We at full-feature PCB assembly Luxembourg are the sole company that offers complete assembly to meet the needs of our esteemed clients. The following is a list of our premium services:
∙ One-Stop Fabrication and Assembly
∙ Multiple Assembly (THT, SMT, Mixed, POP, Rigid boards, Flexible boards) Services
∙ Full turn-key start-to-finish solutions
∙ High volumes Assembly (Series Production)
∙ Low volumes Assembly (Prototypes)
∙ Low Cost with High Efficiency
∙ Durable and reliable component Sourcing from reputable distributors and well-known manufacturers
Quality Control is our main concern, for this we conduct performance tests and when necessary, we perform AIO, X-ray and visual inspection.
One-Stop and Four Types of Circuit Board Assembly Board
We provide our clients with four different types of circuit board assembling services:
Prototype Assembly
Low Volume, High Mix Board Assembly
High Volume Assembly
Partial Assembly
