PCB Manufacturer Liechtenstein

PCB Runner, a PCB manufacturer in Liechtenstein, has experienced notable success during the last ten years. At the moment, our business produces circuit boards with all the required features. At present, we are Liechtenstein’s most well-known solution provider. We provide service to a broad range of industries and have clients all around the world.

Get a Free Quote Now




    PCB Capabilities

    Why PCB Manufacturer Liechtenstein

    Thanks to our modern equipment and incredibly effective processes, we are able to provide our clients high-quality, full-of-feature circuit board services. All our services and products are of the highest quality. Therefore, we serve clients in a range of sectors, such as healthcare, aviation, education, and communication systems.

    PCB Manufacturer Liechtenstein—Our Capabilities

    Our full-featured circuit board manufacturing detailed capabilities are the following



    Parameters

    Specifications For Rigid

    Specifications For Flex

    Maximum Panel Size

    400 mm x 450mm



    Layers

    1-50 layer



    1-20 layer

    Copper Thickness

    Inner (minimum) Hoz – (Max) 6oz

    Outer (minimum) Hoz – (Max) 6oz







    Inner (minimum) Hoz – (Maximum) 3oz

    Outer (minimum) Hoz – (Maximum) 3oz

    Board Material



    FR4: KB6164, KB6167, S1000-2M, S1000H, TG150: KB6165

    Rogers: R4350B, R4003C

    MetalCore: T111 AL

    Halogen: S1150G

    TG135:ShengyiS1141/ KB6160 (CTI175-249)



    Polymide: Thinflex PI, Panasonic PI

    Rogers: NA

    MetalCore: NA

    Halogen: NA

    Inner line width/ Line spacing (original)



    1oz = minimum 3 mil& max no limited

    2oz = minimum 6 mil

    3oz = minimum 8.5 mil

    4oz = minimum 11 mil

    5oz = minimum 14 mil

    6oz = minimum 18 mil



    1oz = minimum 2.5mil & max not limited.

    2oz = minimum 6 mil

    3oz = minimum 8 mil

    Outer line width/ Line spacing (original)



    1oz = minimum 3mil & max: not limited

    2oz = minimum 6 mil

    3oz = minimum 9 mil

    4oz = minimum 12 mil

    5oz = minimum 15 mil

    6oz = minimum 19 mil



    1oz = minimum 3mil & max: no limited

    2oz = minimum 6 mil

    3oz = minimum 8 mil

    Line width tolerance



     minimum +/-10% & max +/-20%



    minimum +/-10% & max +/-20%

    The impedance value and tolerance



     minimum 40+/-5% ohm & max 120ohm +/-10%



     minimum 40+/-5% ohm & max 120ohm +/-10%

    The group of impedance



    minimum & max, no group QTY limited, we can calculate the impedance per your spec





    minimum & max, no group QTY limited, we can calculate the impedance per your spec

    solder mask bridge



    Glossy Colors, Minimum Bridge: 3.5mil





    MATTE Colors, Minimum Bridge: 4mil



    Glossy Colors, Minimum Bridge: 3.5mil





    MATTE Colors, Minimum Bridge:4mil

    Vias

    Blind, Buried, Plugged, Via-in-Pad, Microvia



    Board Thickness

    (minimum & Max):

    0.2-10mm

    (minimum & Max):

    0.1-0.40mm

    Thickness Tolerance

    (minimum & Max):

    +/-0.10mm & +/-10%

    (minimum & Max):

    +/-0.03mm & +/-0.10mm

    Solder Mask



    Type of Color & Glossy/MATTE

    Glossy green/matte green

    Glossy red/matte red

    Glossy blue

    Gossy black/matte black

    Glossy yellow

    Glossy white

    Glossy Purple



    Type of Coverlay Color & soldermask color

    Amber coverlay

    Black coverlay

    Glossy green soldermask

    Glossy blue

    Gossy black

    Surface Finish



    Finish Type with Thickness

    ENIG: gold 1-3u” and Ni 80-160u”

    HASL-LF, Tin thickness is 1-40um.

    OSP: 8-20u”

    Hard gold fingers: gold 3-40u” and Ni 80-160u”

    Immersion silver: Ag 6-15u”

    ENEPIG: gold 1-2u” and Ni 80-120u”, Pa:1-2u”

    Immersion Tin



    Finish Type with Thickness

    ENIG: gold 1-3u” and Ni 80-160u”

    HASL-LF, Tin thickness is 1-40um.

    OSP: 8-20u”

    Hard gold fingers: gold 3-40u” and Ni 80-160u”

    Immersion silver: Ag 6-15u”

    ENEPIG: gold 1-2u” and Ni 80-120u”, Pa:1-2u”

    Minimum dimensions



    Dimensions with routing method

    Min. board size is 20*30mm.

    Min. routing width is 0.8mm



    Dimensions with routing method

    Min. board size is 10*10mm

    Resin Plug Hole(finished)



    Dimensions with routing method

    Min holes size is 0.10mm, max is 0.50mm



    Dimensions with routing method

    Min holes size is 0.10mm, max is 0.50mm

    Castellated Holes



    Clearance with routing method

    min hole is 0.50mm



    Clearance with routing method

    min hole is 0.50mm

    Legend Printing

    White or Custom Colors



    The height/width of silkscreen

    (word height 0.8mm/ word width 0.40mm ratio)2:1

    (word height 0.8mm/ word width 0.40mm ratio)2:1

    The impedance value and tolerance



     minimum 40+/-5% ohm & max 120ohm +/-10%



    The group of impedance



    minimum & max, no group QTY limited, we can calculate the impedance per your spec



    The height/width of silkscreen

    (word height 0.8mm/ word width 0.40mm ratio)2:1



    External dimension tolerance





    ± 5 mil



    ± 5 mil

    The board thickness of V-CUT



    we can only do v-cut for board thickness from 0.60-2.0mm



    ±   mil, o v-cut for flex boards, it’s too thin.

    V-CUT Angle specifications



    20/30/45/60-degree Angles



    Angles, o v-cut for flex boards, it’s too thin.

    V-CUT Angle tolerance



    ±   5degree



    ±   mil—no v-cut for flex boards, it’s too thin.

    BOARD ROUTING METHOD

    CNC

    laser cut and punching

    Edge plating with thickness

    20um copper on edge plating

    15um

    Mini distance between test point and plate edge

    0.2mm

    0.2mm

    Fixture test Max size

    Dimensions (500mm × 600 mm)

    Dimensions (450mm × 558mm)

    Thickness of peelable solder mask



    minimum 0.075 – max 0.20(mm)



    minimum 0.075- max 0.20(mm)

    IPC standard

      IPC-6012

    IPC-6012

    Kapton tape

    Thickness:0.03,0.05, 0.07 mm

    Thickness:0.05mm

    BGA PITCH



    minimum 0.10mm- max 0.12(mm)



    minimum 0.10mm- max 0.12(mm)

    Blind VIA / BURRIED VIA



    minimum – max (mm)

    Stacked 0.10mm

    Staggered 0.10mm



    minimum – max (mm)

    Stacked 0.10mm

    Staggered 0.10mm

    Laser Drill Size



    Minimum (mm) 0.10

    Max (mm) 0.12



    Minimum (mm) 0.1

    Max (mm)0.1

    Aspect Ratio



    Laser Drill (minimum 1:1.3& standard 1:1)

    Mechanical Drill (minimum 1:12& standard 1:8)



    Laser Drill (minimum 1:1 & standard 1:1)

    Mechanical Drill (minimum 1:2& standard 1:1)

    Back drilling

    Yes, we can do it.

    N/A

    Lead Times

    2 days



    In addition, we provide Kapton tape, Carbon mask, and edge plating, Gold fingers, peelable solder masks, etc. To achieve tolerance limits of 10% for impedance control PCBs, we can alter the base material, layer stack up, and other components.

    PCB Manufacturing and Prototype Liechtenstein

    As we provide a range of board types and are exceptionally flexible in our approach to problem-solving, PCB Manufacturer Liechtenstein is the most reputable and trustworthy option for full-feature printed circuit board fabrication.

    We are dealing with the following categories:

    ∙ Multilayer layer PCBs

    ∙ Hybrid RF PCBs, RF Boards

    ∙ Flex and Rigid-Flex PCBs

    ∙ HDI Advanced PCBs

    ∙ Ceramic, High-Temperature Boards, Heavy Copper Boards

    ∙ High-Speed Boards, High-Frequency Boards

    ∙ Metal Core and Aluminum Backed Circuit Boards

    ∙ RoHS Compliant Boards

    Custom PCBs with different shapes

    PCB Assembly Austria
    Flex and Rigid Flex PCB

    PCB Manufacturing and Assembly Capabilities

     Full-feature circuit board manufacturing capabilities are:

    • Quick Turn
    • Prototype
    • Mass Production

    Cost-Free Special Services

    ∙ Electrical Testing

    ∙ Stencil Making

    ∙ DFM and DFA Checks

    ∙ Penalization

    ∙ Consultation to reduce Board Production Costs

    ∙ Custom Layer Stackup

    ∙ Exceptional Client Services

    . Expedited Circuit Fabrication

    Flex and Rigid-Flex PCB Manufacture Liechtenstein

    PCB Runner peruse incredibly in rigid and rigid-flex to provide our valuable customers one-stop quick-turn fabrication and assembly services worldwide. To enable customers to speed up their R&D, we respond to RFQs immediately, carry out DFM checks on the same day, and offer rapid production.


    Types of Flex and Rigid-flex Boards we are offering:

    • Flex Single-sided/Double-sided

    • Rigid-flex single-sided or double-sided

    • Flex with multilayers

    • Multiple layers of Rigid-Flex

    If customers have any requirements, they can consult with our engineering and design services team to choose the best design for their needs. Our quick turn, rapid prototyping service helps our customers assess their new designs quickly.

    PCB Runner— PCB Assembly Liechtenstein

    We provide a comprehensive range of services for assembling PCBs. We provide all of our services, including testing, board assembly, and component sourcing, under one roof. The only company providing full assembly to satisfy our prestigious clients is full-feature PCB assembly Liechtenstein. A list of our premium services is provided below:



    • Services for Multiple Assembly (THT, SMT, Mixed, POP, Rigid boards, Flexible boards)

    • One-Stop Fabrication and Assembly

    • Complete turn-key solutions from beginning to end

    • Low volumes assembly (prototypes)

    • High volumes assembly (series production)

    • An affordable, highly effective component that is reliable and trustworthy. Purchasing from reliable wholesalers and renowned manufacturers

    • Our top priority is quality control; to this end, we carry out performance testing and, if required, AIO, X-ray, and visual inspections.

    One-Stop and Four Types of Circuit Board AssemblyBoard

    We offer four different kinds of circuit board assembly services to our clients:

    ∙ Prototype Assembly

    ∙ High Mix Board Assembly at Low Volume

    ∙ Large-Scale Assembly

    ∙ Full Assembly

    .Partial Assembly
